Max PTZ Control

Cam Menu

Worship

Sermon

Disable

Set

DYNAMIC MOVEMENT

ZOOM OUT

ZOOM IN

PAN LEFT

PAN RIGHT

ATEM PREVIEW

SLIDES

LEFT

CENTER

RIGHT

Cut

Auto

TRANSITION

Left Camera

Center Camera

Right Camera

Drums

Bass

Pads

Guitar

Piano

Left

Mid Left

Center

Mid Right

Right

Stage Wide

Stage Medium

Stage Closeup

Creative 1

Creative 2

Creative 3

Help

Exit

1m 30s

Auto Mix

AF Lock

PLANNING CENTER

CAM MENU

Opens On Screen Display (OSD) menu in PTZ Optics camera. In this menu you can adjust camera settings such as Iris, Shutter Speed, Color Temp, etc.

LAYOUT MODE

Changes "Preset Button" layout between Worship and Sermon. Selecting correct layout will declutter preset buttons during sermon and vise-versa.

DISABLE

Disables not needed preset buttons. When button is activated, touching preset button will disable it. Touching again will enable it.

SET

When button is activated, all preset buttons are in SET mode. When button is not activated, preset buttons are in RECALL mode.

AUTO MIX

When enabled, cameras will automatically transition from left to right. Cycle interval can be adjusted with Auto Mix Time.

AF LOCK

Auto-Focus Lock. When enabled, camera will no longer auto-focus. It is recommended to lock focus to prevent focus ghosting.

JOYSTICK XYZ

Push Stick Forward

CAMERA TILT DOWN

Push Stick Backward

CAMERA TILT UP

Push Stick Left

CAMERA PAN LEFT

Push Stick Right

CAMERA PAN RIGHT

Rotate Stick Head Left

CAMERA ZOOM OUT

Rotate Stick Head Right

CAMERA ZOOM IN

Push Left Head Button

CAMERA FOCUS OUT

Push Right Head Button

CAMERA FOCUS IN

CAMERA SETTINGS

EXPOSURE

Iris: F1.8
Shutter: 1/60
Gain: 1
DRC: 2

COLOR

ColorTemp: 4000K
Saturation: 100%
Hue: 7


Luminance: 7
Contrast: 10
Sharpness: 3
Gamma: Default
Style: Default

NOISE REDUCTION

NR2D-Level: 2
NR3D-Level: 3

JOYSTICK BUTTONS

Button 1

ENTER OR EXIT HELP

Button 2

STOP ALL CAMERAS

Button 3

FOCUS OUT

Button 4

FOCUS IN

Button 5

SLOW ZOOM OUT

Button 6

SLOW ZOOM IN

Button 7

SLOW PAN LEFT

Button 8

SLOW PAN RIGHT

Button 9

SLOW TILT DOWN

Button 10

SLOW TILT UP

Launch App
